Three point panic latch for use on a single door or the active leaf of a pair of rebated doors.

Comprises a mechanism, idler and crossarm with covered connecting rods and horizontal latching pullman latches at the top and bottom.

Suits doors up to 1050mm wide, longer crossarms are available for wider doors upto 1450mm wide and 2585mm high. Longer rods are available to suit doors upto 3150mm high.
Supplied with strikers for timber or metal doors as standard - strikers for PVCu available separately

Available with a dogging (hold-back) facility however this should not be used on fire/smoke door assemblies but fine for escape doors

Micro-switch can be fitted in either the mechanism or idler, this allows the door to be fitted to equipment that monitors the door status. If required state preferred location when ordering.

Optional outside access devices are available to provide entry from outside

Part code - PH3570320
Description - 3 point panic latch, silver

Part code - PH3570325
Description - 3 point panic latch, white

Part code - PH3570301
Description - 3 point panic latch, black

Part code - PH3570344
Description - 3 point panic latch, satin stainless steel plated

Part code - PH3570355
Description - 3 point panic latch, polished stainless steel plated

Part code - PH3570343
Description - 3 point panic latch, polished brass plated

Part code - PH3570382
Description - 3 point panic latch, silver with green cross arm

Part code - PH3570385
Description - 3 point panic latch, white with green crossarm

Part code - PH3570381
Description - 3 point panic latch, black with green crossarm

Part code - PH3570380
Description - 3 point panic latch, black with silver crossarm

If dogging is required use codes above but replace the 3 before the finish code with a 4 e.g.

Part code - PH3570420
Description - 3 point panic latch, silver complete with dogging

If microswitch is required state complete with microswitch fitted in mechanism or idler as appropriate

Other colours and finishes available to special order

Panic devices with crossarm can be fitted to doors in public buildings such as schools, hospitals, retail outlets, nightclubs etc where people are unfamiliar with the surroundings.

PH357 three point latch is suitable for single doors or the active leaf of a pair of rebated doors.

Push bar fitting instructions

Tested and certified to EN 1125:2008 - classification 3-7-7-B-1-4-2-2-A-A

CE / UKCA Marked

Certifire approved 240 minutes
(Certifire CF5394)

Two year warranty (conditions apply)

Declaration Of Performance (CE)

Declaration Of Performance (UKCA)
