SAA (11)

White (25)

Dark Bronze (08)

Suitable most single and double action doors including automatic doors
Roller system finger protection
Provides effective ptection against fingers being accidentally trapped on hinge-side of the door
Strong fire retardent fabric material is kept under constant tension and is designed to cover the gap between the door and the frame automatically when the door is opened.
Easy clean aluminium housing
Cycle tested to 1,000,000 operations
Maximum length 2500mm
Standard length 1925mm
Minimum length 325mm
Maximum fabric travel 260mm
Suitable for use on 60 minute fire doors
Fabric colour Black
Standard finishes for aluminium housing - Satin Anodised Aluminium (SAA), White (RAL 9016) or Dark Bronze Anodised (DBA)
Other RAL colours and anodised finishes available to special order
Lengths between 325mm and 2500mm available to special order, cannot be cut down

FP200X

Standard length  2015mm
EN16005 compliant for automatic doors
Maximum fabric travel 260mm
Fabric colour Black
Standard finishes for aluminium housing - Satin Anodised Aluminium (SAA), White (RAL 9016) or Dark Bronze Anodised (DBA)
Other RAL colours and anodised finishes available to special order

Part code - AFP200I11
Description - FP200 finger protector 1925mm SAA
Pack size - 10 (can be supplied in any quantity)

Part code - AFP200I08
Description - FP200 finger protector 1925mm Dark Bronze Anodised
Pack size - 10 (can be supplied in any quantity)

Part code - AFP200I25
Description - FP200 finger protector 1925mm White
Pack size - 10 (can be supplied in any quantity)

Part code - AFP200X11
Description - FP200 finger protector 2015mm SAA
Pack size - 10 (can be supplied in any quantity)

Part code - AFP200X08
Description - FP200 finger protector 2015mm Dark Bronze Anodised
Pack size - 10 (can be supplied in any quantity)

Part code - AFP200X25
Description - FP200 finger protector 2015mm White
Pack size - 10 (can be supplied in any quantity)

Other sizes and finishes available to special order

FP200 finger protector can be fitted to most doors. They are generally specified in schools, nurseries, hospitals, shops, restaurants and other buildings open to the general public.

FP200X is for automatic swing doors which have to have finger protection effective to 2 metre high to comply with EN16005.

FP200 Fitting Instructions

Tested to 1,000,000 operations

Comply with EN16005 (2015mm)

Tested to EN16654

Achieved German Safety Mark

Approved for 60 minute fire doors

Tested to BS8613 - Class 2

Lifetime warranty (conditions apply)

Cleaning Detergents Information
